KNF chemically resistant membrane metering pump SIMDOS® 10 FT.18 RC P2. Flow rate of 1. 100 ml/min / pressure height 60 mWS, suction height 3 mWS. Pump head made of PTFE material. Diaphragm made of PTFE, valves made of FFKM. Flow rate can be adjusted manually and by means of external control and includes an RS 232 interface (RC Plus version). Additional safety membrane for maximum protection. Easy replacement of the conveyor diaphragm by activating the maintenance command stored in the operating program. Technical data Application Dosing of liquids Flow rate (ml/min) with water at 20 °C at zero head 1. 100 Pressure head (mWS) 60 Suction head (mWS) 3 Hose connection (mm) ID4 / AD6 Permissible media and ambient temperature Ambient temperature +5 . +40 °C Media temperature +5 .. +80 °C Weight (kg) 0.9 Dimensions W x H x D (mm) 93 x 144 x150 Pump head material PTFE membrane PTFE valves FFKM Included in the scope of delivery: -dosing pump -suction filter - 2 meter connection hose - AC adapter Accessories (not included in the scope of delivery) Tripod mount Order no. 160474 wall bracket part no. 160473 Foot switch for RC version (RC = manual operation and external control) Order no. 155872 In-line filter FS 25 T PVDF mesh size 70 µm part no. 165211 FS 25 X PEEK mesh size 35 µm part no. 165213 NEW DEVICE. Manufacturer's guarantee!
